Product Overview
6 Bedroom Container Home is a compact two-level concept based on a standard 40-foot container footprint. It is engineered for durability and quick deployment, offering private sleeping areas, a living room, kitchen zone, bathroom and an outdoor balcony option. Insulated wall and ceiling panels help regulate temperature for year-round use.
Designed for portability and fast on-site setup, the structure folds for transport and unfolds for installation. This approach shortens build time and keeps costs under control while maintaining comfort and a clean, modern interior.
 |  |  |
Configuration
| Section | Item | Data |
|---|---|---|
| Basic Features | External dimensions (mm) | 6300*11800*2480 |
| Basic Features | Internal dimensions (mm) | 6000*11400*2240 |
| Basic Features | Folding state (mm) | 2200*11800*2480 |
| Basic Features | Total weight | 7 ton |
| Frame Structure | Top girder | Thickness 2.5mm Q235B |
| Frame Structure | Bottom girder | Thickness 2.5mm Q235B |
| Frame Structure | Side girder | Thickness 1.5mm Q235B |
| Frame Structure | Middle column | Thickness 2.5mm Q235B |
| Frame Structure | Sidewall frame | Thickness 1.5mm Q235B |
| Frame Structure | Subframe | Thickness 1.5mm Q235B |
| Frame Structure | Hanging head | Thickness 4mm Q235B |
| Frame Structure | Folding hinge | 13mm galvanized hinge |
| Frame Structure | Protective coating | Electrostatic spraying / direct white plastic powder |
| Frame Structure | Middle cabinet top & bottom | 150*100 |
| Frame Structure | Top & bottom of side cabinet | 80*160*1.5 thickness square pipe |
| Top of Box | External roof | Thickness 0.5mm galvanized sheet |
| Top of Box | Inside ceiling board | Thickness 831 inside ceiling board |
| Wallboard | Middle roof insulation | T150mm glass wool |
| Wallboard | Side/front/rear wall panels | Thickness 150mm glass wool galvanized sheet or Thickness 150mm foam board |
| Wallboard | Internal partition | T150mm foam board |
| Wallboard | Internal toilet | 1700*1500 (can be customized) |
| Floor | Middle floor | Fireproof glass magnesium floor (15mm) |
| Floor | Floor on both sides | Bamboo wood floor |
| Electrical System | Specification | Wiring and installation per moisture-proof specifications; all electrical products meet CE certification. Indoor: 2 LED lights, 2 ceiling lights, 5 single socket 3, single socket 1, 10 socket 3, air-conditioning socket 1, 20A leakage protector; Voltage: 220V, 50HZ. |
| Openings | Security door | 2 or customized |
| Openings | Window | 4–10 (920*1120mm) |
| Quality | Quality assurance | One year |
Description
If you need an affordable private cabin, 6 Bedroom Container Home offers a foldable, expandable structure that ships as a compact unit and unfolds on site. Major accessories are pre-installed at the factory to speed up commissioning—unpack, expand and complete the basic hookup before moving in.
Features
- Portable and space-saving: collapsible body ships efficiently, reducing transport volume and cost.
- Customizable appearance: optional exterior cladding, roof treatments and decks for a refined look.
- Multi-function layout: supports separate living, sleeping, kitchen and bathroom zones for comfortable daily use.
- Resilient materials: fire- and water-resistant components help lower maintenance over time.
Our Service
Production uses advanced equipment and a documented quality system. A dedicated engineering team oversees design, fabrication and inspection to support reliable delivery and performance.
